PARAMETER
| Model | MBQ640A |
| Machine parameter | |
| Working width | 25-400mm |
| Working thickness | 8-320mm |
| Feeding speed | 7-35m/min |
| Main shaft diameter | 1600mm |
| Spindle diameter | Φ50mm |
| Axial movement | 0-20mm |
| Main shaft revolution | 6000r/min |
| Pneumatic source pressure | 0.6Mpa |
| Motor power | |
| First bottom spindle | 15kw |
| Right side spindle | 11kw |
| Left side spindle | 11kw |
| First top spindle | 15kw |
| Second top spindle | 15kw |
| Second bottom spindle | 15kw |
| Feed | 11kw |
| Feed beam rise&fall | 0.75kw |
| General power | 93.75kw |
| Cutting circle(mm) | |
| First bottom spindle | Φ125-Φ160 |
Right side spindle | Φ125-Φ180 |
| Left side spindle | Φ125-Φ180 |
| First top spindle | Φ125-Φ180 |
| Second top spindle | Φ125-Φ180 |
| Second bottom spindle | Φ125-Φ160 |
| Remarks/mm | |
| Dust outlet diameter | Φ140mm |
| Feeding wheel diameter | Φ140mm |
| Overall Dimensions(mm) | 5560*2025*1900 |
| Net weight | 7000kg |
